S-Locks M
S-Locks M
From €26.20*
Prices incl. VAT plus shipping costs
available, delivery time appr. 1-3 days Germany, 3-5 days Europe, 5-7 days other countries
Product Configurator
S-Locks size M: thread length 22 mm
With Schaller Security Locks, we developed and patented a completely new product in 1981, probably the most secure connection between guitar and strap. In 2018, the next generation was introduced with the S-Locks.
Note: before installation please read the following
Concept and features
S for safe, silent & Schaller strap locks
- unique one-piece hardened steel strap buttons
- S-Locks suitable for different belt thickness with ergonomic operation
- and a patented locking nut - Lock-Wheel - with triple security architecture
(Fig. 1: one set of S-Locks complete with strap button)
The S-Locks strap button
- new and unique one-piece construction, easy to install via 3 mm (1/8") allen key
- special 4.0 mm wood thread in S-Lock size M for maximum grip. Optionally available in sizes S (3.5 mm) and L (4.5 mm). Please refer to the installation guide above.
- hardest steel for maximum wear resistance and safety
- including high-grade felt washers to protect your instrument
The S-Locks improved lock
- extended thread length for holding straps of up to 6 mm thickness
- newly designed slanted locking bolt made of stainless steel for minimum wear and thus maximum safety
- new design pull-up ball for best haptics
- suitable for a standard hole in the belt of 10 mm
The improved S-Locks-Wheel: featuring 3-stage safety concept
- Lock-Wheel with special patent thread ensures a secure hold. It can be tightened safely by hand without tools.
- The 2-hole mount (suitable for 2 mm Allen key or screwdriver) allows a firmer tightening torque of the Lock-Wheel with maximum hold.
- Undetachable hold due to grub screw with tapered cap and slot 2.5 x 5 mm made of stainless steel. Simply unscrew the set screw again to unscrew the Lock-Wheel; the thread remains functional and cuts itself "free" again through the Lock-Wheel.
Final
- Put all parts together and give it a shake
- Sounds of silence - You will be amazed: Whether on stage or in the studio, S-Locks do not rattle.
Compatibility Schaller Security Locks and S-Locks
a.) S-Locks are compatible with all existing Schaller Security Locks like this:
- strap button old SecLock + lock new S-Lock (without silent feature!)
- strap button new S-Lock + lock old SecLock only limited, we do not recommend it.
Please always use our new S-Lock lock with Lock-Wheel on your strap, then you will always be compatible with all strap buttons and at the same time you will always use all the advantages of our new Lock-Wheel.
Please always make sure that the lock is engaged in the strap button, the lock is attached to the belt in such a way that the strap button is secured in the U-shape of the lock and that the instrument does not rotate.
b.) One strap for several instruments
Choose from more matching strap buttons in different lengths here:
- Strap Buttons size S: male thread 3.5 mm, inside 2.4 mm, length 18 mm
- Strap Buttons size M: male 4.0 mm, inside 3.0 mm, length 22 mm - most commonly used
- Strap Button size L: male 4.5 mm, inside 3.2 mm, length 27 mm
Schaller S-Locks: only original in the pictured crystal box
(It can also be used as a sustainable storage container after removal of the protective foam.)
The package contains:
2 x Strap Buttons with high-grade felt washers
2 x Locks
2x Lock-Wheels
(Technical drawings without engagement)
Technical drawings
